Sunshade Net Inspection and Rolling Machine
Purpose：
SB-IRM-6 Sunshade Net inspection and rolling machine is mainly used in sunshade net factory to inspect and wind big rolls to small rolls to guarantee the best transporting package.
Features：
- Frequency steeples speed regulation
- Configuring a professional repair table cloth floating roller turned negative regulator repair
- Photoelectric device for automatic edge-alignment
- No cloth stopping device
- Electronic length meter (amends, determines and totalizes the fabric length in metre, yard as well as displays the rolling speed)
- Optional computer interface
- Optional defect counter and computer control systems, which can be accumulated on the various types of defect count timely and accurate location and print out the defect level, a true reflection of the actual quality of cloth
Specification:
|
Model |
SB-IRM-6 |
|
Speed |
0-60m/min |
|
Fabric Width |
3.2---4.5m |
|
Max un-winding Diameter |
1000mm |
|
Max re-winding Diameter |
800mm |
|
Dimension(L*W*H) |
4325*5610*2520mm（take example for fabric width at 4500mm ） |
|
Weight |
3500kgs（take example for fabric width at 4500mm ） |
|
Electric specification |
Three Phase-380V, 50Hz(can be adjusted to suit for different countries) |
|
Power |
3.5KW |
|
Remark |
Variable working width is possible and can be tailor made to your requirements of processing needs |
|
For Price Inquiry |
1. What is the fabric type? 2. What is the max fabric width? 3. What is the fabric inlet form? 4. What is the fabric outlet form? |
